2016 Mazda MX-5 Miata mechanical cutaway showing drivetrain and chassis layout
- 521 views
- View William Maley's images
A cutaway transparency rendering of the 2016 Mazda MX-5 Miata revealing the front-engine, rear-wheel-drive mechanical layout, including the inline-4 engine, 6-speed transmission, and lightweight chassis structure. The image illustrates Mazda's focus on weight distribution and platform engineering for the fourth-generation Miata.
