2016 Chevrolet Volt at Detroit Auto Show — Voltec electric motor exploded view illustration
By Drew Dowdell
- 915 views
- View Drew Dowdell's images
Technical exploded-view illustration of the 2016 Chevrolet Volt's second-generation Voltec electric drive motor, showing the copper stator windings, rotor assembly, bearing, and reduction gear ring. The updated Voltec propulsion system delivers improved efficiency and stronger acceleration compared to the first-generation Volt.
