Mazda MX-30 Battery Pack Exploded View

Drew Dowdell

By Drew Dowdell

 Share
A studio rendering showing the Mazda MX-30's battery pack in an exploded view, with the lithium-ion battery modules, cooling system piping, and structural floor tray separated to reveal the assembly layers. This illustrates how the 35.5 kWh battery integrates into the vehicle's platform.
