2014 Cadillac ELR Base Coupe Voltec powertrain and battery pack cutaway illustration

By William Maley

A transparent cutaway illustration of the 2014 Cadillac ELR reveals the Voltec extended-range electric powertrain, with the large T-shaped lithium-ion battery pack running through the center of the vehicle. A charging cable connects to the front port, highlighting the ELR's plug-in capability as the technological centerpiece of the coupe.
  •

    From the album:

    2014 Cadillac ELR

    · 12 images
