An overhead diagram from Chevrolet illustrates the complete hybrid powertrain layout of the 2016 Malibu Hybrid, with callouts identifying the lithium-ion battery system positioned under the rear seat and the 1.8-liter engine and drive unit at the front. Orange high-voltage cables connect the two systems, a layout borrowed from the Chevrolet Volt's development program.
